VPN – Cisco Meraki Security Appliance

In this topic, you will learn how to configure the Cisco Meraki Security Appliance to work together with Portnox™ Cloud and 802.1X RADIUS authentication for VPN connections.

Warning: This topic contains documentation prepared by our support agents more than 12 months ago. It may not cover the newest models or the newest interfaces of NAS devices. We’re working on bringing you updated documentation for NAS devices in the near future. However, the methods of setting up third-party devices may still change when the manufacturers update their firmware or release new models. Therefore, to get the most accurate and current configuration guidance, we strongly recommend that you refer to the documentation provided by the manufacturer. If you need help setting up newer equipment that does not match the description in this topic, contact us at support@portnox.com.
In the Meraki web interface, navigate to Security Appliance > Client VPN and perform the following:

  1. Set Client VPN server to Enabled.
  2. Specify the Client VPN subnet.
  3. Enter a Secret to be used in the VPN client.
  4. In Authentication, select RADIUS.
  5. In RADIUS servers, click on Add a RADIUS Server and enter your cloud RADIUS details for RADIUS authentication (not accounting).
  6. Optional: If necessary, click on Add a RADIUS server and repeat the above step for the second cloud RADIUS server and/or the local RADIUS server.
  7. Click on Save Changes.
